| Brand |
Inogen |
| Oxygen Concentration |
90% - 3% / + 6% at all settings |
| Flow Control Settings |
Pulse dose settings 1, 2, 3, 4 |
| Maximum Outlet Pressure |
<22 PSI |
| Inspiratory Trigger Sensitivity |
<0.12 cmH₂O |
| Nominal Sound Level |
39 dBA at setting 2 |
| AC Power Input |
100-240 VAC, 50-60 Hz, 2.0-1.0 A |
| DC Power Input |
12.4-15.1 VDC, 100 W max |
| Power Consumption |
85 W max |
| Battery Type |
Lithium-ion |
| Operating Temperature |
41°F to 104°F (5°C to 40°C) |
| Operating Humidity |
15% to 90%, non-condensing |
| Operating Altitude |
0 to 10,000 ft (0 to 3048 meters) |
| Storage Temperature |
-13°F to 158°F (-25°C to 70°C) |
| Storage Humidity |
5% to 90%, non-condensing |
| Model |
IS-401 (Rove 4) |
| Weight |
2.9 lb with the 4-cell standard battery, 3.4 lb with the 8-cell extended battery |
| Dimensions |
5.9 x 2.7 x 7.5 in (standard battery), 5.9 x 2.7 x 8.1 in (extended battery) |
| Maximum Oxygen Output |
840 mL/min (setting 4) |
| Battery Duration |
At setting 2 (Inogen manual): more than 2 hours (4-cell standard) or more than 4 hours (8-cell extended). Inogen also lists up to 3 hours (standard) and up to 5.75 hours (extended). |
| Recharge Time |
Up to 3 hours 30 minutes (4-cell standard) or up to 4 hours (8-cell extended) |
| Warm-Up Time |
2 minutes |
| Air Travel |
Meets FAA acceptance criteria for use onboard aircraft |
| Expected Service Life |
Up to 8 years |
| Warranty |
3-year manufacturer warranty on the device |
| Prescription |
Required |
